■ 說明:
●導體使用單條或絞線,30-16AWG,裸軟銅或鍍錫軟銅線
●PVC絕緣
●額定溫度: 80℃; 額定電壓:300Volts
●可通過UL-VW-1垂直耐燃測試
●使用標準厚度,易剝,截斷容易
●參考標準:UL subject 758;UL 1581
■ 應用:
●一般電子,電器設備內部配線,如機械動作令其磨損,需作適當保護。
■ PRODUCT DESCRIPTION
●Tinned or bare , stranded or solid copper conductor,30-16AWG
●Color-coded PVC insulation
●Rated temperature:80 ℃ . Rated voltage:300 volts.
●Passes UL VW-1 vertical flame test.
●Uniform thickness of wire to ensure easy stripping and cutting .
●Reference standard : UL subject 758, UL1581
■ APPLICATIONS :
●For general purpose internal wiring ofelectronic and electrical,protection is required where mechanical demage
■ 產品結構 CABLE CONSTRUCTION | |||||
Conductor 導體 | InsuIation Thickness | Overall Diameter | Maximum Resistance at 20℃ | ||
線號 | 線數/ 線徑 | 外徑 | 絕緣厚度 | 完成外徑 | 最大導體電阻 |
AWG | No./m m | mm | mm | mm | ohm/km |
30 | 7/0.102 | 0.30 | 0.34 | 0.96 | 354 |
28 | 7/0.127 | 0.38 | 0.34 | 1.06 | 223 |
26 | 7/0.16 | 0.48 | 0.36 | 1.20 | 139 |
24 | 11/0.16 | 0.61 | 0.34 | 1.29 | 88.9 |
22 | 17/0.16 | 0.76 | 0.34 | 1.44 | 57.5 |
20 | 26/0.16 | 0.94 | 0.34 | 1.66 | 34.6 |
18 | 41 /0.16 | 1.18 | 0.34 | 1.86 | 23.3 |
16 | 26/0. 254 | 1.49 | 0.34 | 2.18 | 15.1 |
