UL2854是網絡(luò )線的美國安規認證型號，線材結構是芯線兩兩對絞的信號傳輸作用,并且外層會(huì )帶屏蔽的編織網還有鋁箔等防干擾，UL2854一般使用的芯線是26AWG，28AWG的大小，芯線大小做0.95MM,方便打水晶頭。

UL 2854 Multi-Core Shielded Wire 多芯隔離線

■  PRODUCT DESCRIPTION
● Tinned or bare,stranded or solid copper conductor,30-18 AWG.
● Color-coded PVC insulation similar to UL1061.
● Tinned or bare copper wire spiral shield.
● PVC jacket.
● Rated temperature：80℃. Rated voltage：30 volts.
● Passes UL VW - 1SC vertical flame test.
● Reference standard：UL subject 758，UL 1581.
■ APPLICATIONS
● For use in recording studios,sound systems and electronic circuits.

■ 說明：
● 導體使用絞線，30 - 18AWG裸軟銅或鍍錫軟銅線
● 半硬PVC絕緣，芯線類似UL 1061
● 裸軟銅或錫軟銅線纏繞隔離
● PVC被覆
● 額定溫度：80℃；額定電壓：30Volts
● 可通過UL VW-1SC 垂直耐燃測試
● 參考標準：UL 758，UL 1581
■ 應用
● 用于錄音，錄音工作室，音響系統，電子電路。
